Exterior LED Channel

order code: product-title.colourtemp.lamp type.length.finish

example: exterior-led-channel.3000K.high output.1500mm.clear anodised

Back to products
Back To All

Micro G3.2 LED Strip potted into 16.5mm x 16.5mm channel. IP66 rated for exterior use. Maximum continuous length: 2m. Drawing shows mounting tabs, other mounting options are available.

Photometry is commonly available for currently preferred light sources. Equivalent and alternative light sources can be used depending on availability or desired specification. In this way, Stoane Lighting can react quickly to supply chain issues and tailor products to specific customer requirements.

Light Source Type
  • LED Strip
Usage Type
  • IP Rated for Exterior Use
Mounting Method
  • Surface
Material
  • Machined Aluminium
  • Acrylic Cover
  • Acrylic Diffuser
Light Source
  • G3.2 Standard Output LED Strip
  • G3.2 High Output LED Strip
Colour Temperature
  • 2700K
  • 3000K
  • 4000K
CRI Ra
  • Min. 95 (typ.97)
Initial Output (Wattage)
  • Standard Output: 1496lm/m (16.8W/m)
  • High Output: 2702lm/m (31.2W/m)
IP Rating
  • IP66
Finish
  • Anodised
  • Painted
Dimming
  • 0-10V
  • DMX
  • DALI
  • Wireless
Supply
  • 24V PSU required
Pan & Tilt
  • ±90 Tilt with Optional Mounting Tabs
Optic
  • N/A
