VCL.Clamp
Flexible and portable task lighting system, designed to enhance the workspace in home working and office environments.
Product Description
The Video Conferencing Light has been designed and developed to address good quality task lighting for the home working and office environment. VCL.Clamp has a high quality glass base by which a device can rest in the dedicated groove. It is available in a choice of finishes, and some elements can be customised such as height and dimming. Includes toughened glass diffuser with adjustable kick reflector for soft distribution of light.
Key Features
• Optional phone cradle.
• Desktop and clamp versions available.
• Adjustable kick reflector to allow easy of adjustment of light effect from work surface to wall/ face during video conferencing.
• Sustainable construction: made from recycled aluminium with a long-lasting anodised finish. Specialist finishes such as stainless steel anodised effect or RAL finishes available on request.
• Advanced dimming options: On-board and Wireless dimming, down to 0.1%.
Compliance
Environmental
TM65.2
CIBSE’s TM65.2 provides a calculation methodology to assess the embodied carbon in lighting products.
TM66
CIBSE’s TM66 includes a calculator called the Circular Economy Assessment Method (CEAM). An independent metric assessing a luminaire’s Circular Economy credentials in terms of product design, materials, manufacturing and ecosystem.
vcl.clamp - 2.6
LCA and EPD
A report containing Life Cycle Assessment results, including environmental impacts across the full life cycle of the product. Impacts cover a wide range of effects on the environment, in addition to carbon emissions.
Please contact the Specifier Support team should your project have a requirement for additional environmental reporting. For more information, please click here.
Service Commitment
Electrical
Supply
Remote constant current LED driver required
Power
8.6W
Vf 34.7V
Technical
Light Source
9mm LES COB
90 CRI 250mA
816lm initial output at 3000K 94.9lm/W
Light Distribution
Full 144.7°
Tilted 173°
Half Tilt 216°
IP Rating IP20
Weight 1.435kg
IP Rating: IP20
Weight: 1.435kg
Photometry
These files represent the highest available initial output for each light source in 3000K. Lower outputs and other colour temperatures are available.
90 CRI (816lm initial output)
Full 144.7°
Tilted 173°
Half Tilt 216°
