Surf S Tree

order code: product-title.colourtemp.optic.height.finish

example: surf-s-tree.3000K.medium.1000mm.clear anodised

Back to products
Back To All

Versatile vertically mounted post supporting a variable number of powerful adjustable and lockable Surf Type S spotlights at custom pitches. Ø10mm cutout required.

Note: A Surf S Tree to be installed in vertical orientation only. Maximum height of the Surf S Tree is 1.3m. If a taller fitting is needed then extra support will be required. Our Specifier Support team will work with you to find a suitable solution. Get in touch with them via [email protected]

Photometry is commonly available for currently preferred light sources. Equivalent and alternative light sources can be used depending on availability or desired specification. In this way, Stoane Lighting can react quickly to supply chain issues and tailor products to specific customer requirements.

Light Source Type
  • Discrete LED
Usage Type
  • Interior Use Only
Mounting Method
  • Surface
Material
  • Machined Aluminium
Light Source
  • Type S (1 x Osram Oslon Square)
Colour Temperature
  • 2700K
  • 3000K
  • 3500K
  • 4000K
CRI Ra
  • Min. 95 (typ.97)
Initial Output (Wattage)
  • 100lm at 350mA (1W)
  • 137lm at 500mA (1.4W)
IP Rating
  • N/A (interior use only)
Finish
  • Anodised
  • Painted
Dimming
  • 0-10V
  • DMX
  • DALI
  • Mains Dim
  • Wireless
Supply
  • Remote Constant Current LED driver required
Pan & Tilt
  • ±90º Tilt
Optic
  • Very Narrow
  • Narrow
  • Medium
  • Flood
  • Wide Flood
  • Asymmetric
